1394B Male 9Pin IEEE 1394 Firewire Cable Assembly A To B Adapter Cable for Indutrial Camera
Product Description
1. Transferring digital data between computers and industrial
camera or 1394B 9pin interface devices.
2. Supports IEEE 1394 transfer rates of 100/200/400/800 Mbits
3. Fully Firewire B compatible
4. Overmolded connectors with screw locks at two ends,fixed firmly
with industrial equipment and component.
5. Length 1~15meters available.3.28feets to 49.2feets available
,14.75 feets length cable with stock for immediately shipment.
firewire cable standard length 1m,2m,4,5m,7m and 10m,some 15meters.
6. Color: Black
7, IEEE 1394b 9PIN Male / Female,straight or right angle connection
type all available.
8, Quick release latches or High Quality Thumbscrews locking type available.
9, Standard cable and ultra high flex cable for options,with ferrite or not is ok,OEM/ODM service also accepted. The Barcode, color, length or other specification can be custom
10, 9 pin to 9 pin cable is also available for connecting Firewire-800(1394B pin) devices on a 9 pin Firewire-800(1394B9pin) port. 6 pin plug to 6 pin plug with locking screws at the 6 pin end, 400 Mbps cable available
Specifications:
Physical | Cable Color | Black |
Connector | 1394B Male 9pin | |
Jacket Material | UL 80℃ PVC (-20 ~80 ) | |
Shell Material | PVC or PU | |
Shell Color | Black | |
Shell Construction | Pre mold in Poly Ethelene wrapped 360 degrees with copper tape terminated to shield, overmolded in black PVC. | |
Cable construction | 20276 80 30V VW-1 IEEE 1394 SERIAL BUS CABLE [(26AWG×1P+2D+CU-PT+M)×2PCS+(22AWG×2C)]+M+AM+B BLACK PVC JACKET. | |
Electrical | Voltage Rating | 30V |
Current Rating | 1A | |
Insulation Resistance | Min. 100 mega ohms-km at 20 | |
Dielectric Test | 500 VAC /1 min ; No Breakdown | |
Impedance | 33 ± 6 ohms (Common mode at TDR) 110 ± 6 ohms (Differential mode at TDR) | |
Propagation Delay Skew | Max. 160 ps/4.5m | |
Propagation Delay | Max.5.05 ns/m | |
Temperature Rating | - 40 to +80 Celsius degree | |
Applications:
Indutrial Camera | AVT,IMMAGINGSOURCE,DALSA,BASLER,COGNEX,CORECO,ADIMEC,EURESYS,JAI, IMPMEX,MATROX,DTA,PULNIX,EVISION,PLEORA,TOSHIBA TELI,SONY,NATIONALINSTRUMENT,REDLAKE,UNIQ,IDT,DVC,SILICONIMAGING,OMRON, PELCO,SENTECH,EPIX…… |
Imaging frame grabber | AVT,IMMAGINGSOURCE ,CORECO,EPIX,EURESYS,FORESIGHT,MATROX,EVISION,NATIONAL INSTRUMENT…… |
Machine vision | For all 1394B standard interface |
Equipment Systems | Automatic Optical Inspection system(AOI), Mould monitor, Robot device,Machine Arms,Medical Equipment,Factory Equipment…… |
Competitive Advantage:
1, OEM SERVICE(FACTORY WITH EXPERIENCED RD DEP.)
2, GOOD QUALITY,HIGH FLEX,CHAIN FLEX CABLE
3, GOOD PRICE
4, SHORT TIME DELIVERY TIME
5, NICE SERVICE
|
|
